EXTREME 100G SR4 QSFP28 100m

A 100GBASE-SR4 QSFP28 module built to the IEEE 802.3bm Clause 95 specification. This QSFP28 transceiver module provides a maximum data transfer rate of 100 Gbps up to 100m over multimode fiber cable. Used for 100 Gigabit Ethernet uplinks, switch fabric, and short-reach data-center interconnect over multimode fiber.

Form Factor: QSFP28 Interface: 100GBASE-SR4 Fiber Type: Multimode Fiber (MMF) Connector: MPO-12 (8-fiber parallel) Wavelength: 850nm (four VCSEL lanes) Data Rate: 100 Gbps (four 25.78125 Gbps lanes) Maximum Distance: 100m over OM4, 70m over OM3 Operating Temperature: 0°C to 70°C Storage Temperature: -40°C to 100°C Digital Optical Monitoring (DOM): Yes Standards: QSFP28 MSA, SFF-8636, IEEE 802.3bm, CAUI-4 Certifications: CE, FCC, RoHS compliant Laser Class: Class 1 Dimensions: 57mm × 15mm × 9mm (L × W × H)
