Features:
The panoramic viewing angle, large size, and 5K definition blend together to create a display that seamlessly matches the demands of hybrid working, commercial display, command & control, and a host of other professional situations.
- 92'' 5K (5120x2160) Resolution display
- 21:9 Aspect Ratio
- 600 Nit
- Ultra-wide panoramic vision
- Portrait and Landscape mode
- Empowered by Microsoft Teams Rooms
- 8GB Ram, 64GB Rom
- Maxhub Meeting OS V6 System
Specifications:
Display
- Model: UW92NA
- Screen Size (Inch): 92
- Aspect Ratio: 21:9
- Panel: VA
- Backlight: DLED
- Brightness: 600 nits
- Haze: 25%
- Resolution: 5120 × 2160
- Refresh Rate: 60Hz
- Contrast Ratio: 5000:1 (typ.)
- Viewing Angle (H / V): 178° / 178°
- Display Orientation Landscape / Portrait
- Operation Hours (Hours / Day): 24 / 7
- Response Time: 6.5ms
- Life Time (50%): =50,000 hours
Built-in System
- Operating System: Android 13.0
- CPU: A76 × 4 + A55 × 4
- GPU: Mali-G610 MP4
- RAM: 8 GB
- ROM: 64 GB
- System OS: MAXHUB Meeting OS V6
- Screen share: MAXHUB Share Support BYOM / Miracast / Airplay / Chromecast
- Device Management: MAXHUB Pivot
- Protocal Control: RS232 / IP control
- Special Features: Screen rotation / Auto input change / Play via URL / Wake on LAN / HDMI CEC / Compatible with control systems (Crestron, Q-SYS, and Extron)
Connectivity
- Input:
- HDMI IN × 4 - HDMI 2.0 × 3, HDMI 2.1 × 1
- USB 2.0 × 1
- USB 3.0 × 4
- USB Type-C × 1
- DP IN × 1
- AUDIO IN × 1
- RS232 × 1
- RJ45 IN × 1
- Output
- HDMI OUT × 1
- TOUCH 2.0 × 3
- AUDIO OUT × 1
- SPDIF × 1
- RJ45 OUT × 1
- OPS Slot: Module slot × 1
- Wi-Fi: Wi-Fi 6
- Bluetooth: 5.2
Audio:
- Sound Channel: 2.1
- Speaker Power: 2 × 20W + 20W
Power:
- Power Supply: 100-240V~50/60Hz
- Power Consumption (Energy Saving): 177 W
- Power Consumption (Typ.): 320 W
- Power Consumption(Max.): 530 W
Physical Specification:
- Bezel Width (L × R × T × B): 17.9 / 17.9 / 17.9 / 17.9 mm
0.7 / 0.7 / 0.7 / 0.7 inch
- Dimension(W*H*D): 2182 × 944 × 85 mm
85.90 × 37.16 × 3.35 inch
- Shipping Dimension(W*H*D): 2360 × 1072 × 225 mm
92.91 × 42.20 × 8.86 inch
- VESA: 800 × 600 mm
- Net Weight: 43.40 Kg
- Gross Weight: 62.60 Kg
Environmental Conditions
- Operating Temperature: 0°C~40°C
- Storage Temperature: -20°C~60°C
- Operating Humidity: 10%~90%RH
- Storage Humidity: 10%~90%RH
Certification
- Energy Star: Y
- IP Rating: IP5X
Warranty:
- Display: 3 years warranty
Accessories
- Power Cord
- HDMI Cable
- Remote Control
- Wall Mount
- Wireless Adapter
Optional Module
- OPS: OPS62A / OPS72A
- Mobile Stand: ST41B / ST23C
