Description
Designed for use in 10-Gigabit Ethernet links up to 40km over single mode fibre. The module consists of 1550 EML Laser, InGaAs PIN and Preamplifier in a high-integrated optical sub-assembly. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF8472. The module data link up to 40km in 9/125um single mode fibre.FEATURES Up to 11.1Gbps Data Links Up to 40km transmission on SMF EML transmitter and PIN receiver Metal enclosure, for lower EMI 2-wire interface with integrated Digital Diagnostic monitoring Hot-pluggable SFP+ footprint Specifications compliant with SFF 8472 Compliant with SFP+ MSA with LC connector Single 3.3V power supply Case operating temperature range: 0°C to 70°C Power dissipation < 1.5 W APPLICATIONS 10GBASE-ER/EW & 10G Ethernet STANDARDS Compliant to SFF-8431 Compliant to SFF 8472 RoHS Compliant WARRANTY3-years limited warrantyTAA-approved SFPs available upon request, Contact us for more details.
