AMD Ryzen 5 9600X 6Cores/12Threads, 65 watts, Max Boost Clock 5.4 GHz, PCIE 5.0, 32MB Cache, Radeon™ Graphics, 2200 MHz Frequency

AMD Ryzen 5 9600X 6Cores/12Threads, 65 watts, Max Boost Clock 5.4 GHz, PCIE 5.0, 32MB Cache, Radeon™ Graphics, 2200 MHz Frequency General Specifications Form Factor: Desktops , Boxed Processor Market Segment: Enthusiast Desktop AMD PRO Technologies: No Former Codename: Granite Ridge AM5 Architecture: Zen 5 # of CPU Cores: 6 Multithreading (SMT): Yes # of Threads: 12 Max. Boost Clock: Up to 5.4 GHz Base Clock: 3.9 GHz L1 Cache: 384 KB L2 Cache: 6 MB L3 Cache: 32 MB Default TDP: 65W Processor Technology for CPU Cores: TSMC 4nm FinFET Processor Technology for I/O Die: TSMC 6nm FinFET Package Die Count: 2 CPU Socket: AM5 Supporting Chipsets; A620 , X670E , X670 , B650E , B650 , X870E , X870 CPU Boost Technology: Precision Boost 2 Instruction Set: x86-64 Supported Extensions: AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 Thermal Solution (PIB): Not Included Recommended Cooler: Premium air cooler recommended for optimal performance *OS Support: Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit Connectivity Native USB 3.2 Gen 2 (10Gbps) Ports: 4 Native USB 2.0 (480Mbps) Ports: 1 PCI Express® Version: PCIe® 5.0 Native PCIe® Lanes (Total/Usable): 28 , 24 Additional Usable PCIe Lanes from Motherboard X870E 8x Gen4 X870 4x Gen4 X670E 12x Gen4 X670 12x Gen4 B650E 8x Gen4 B650 8x Gen4 NVMe Support: Boot , RAID0 , RAID1 , RAID5 , RAID10 System Memory Type: DDR5 Memory Channels: 2 Max. Memory: 192 GB System Memory Subtype: UDIMM Max Memory Speed 2x1R DDR5-5600 2x2R DDR5-5600 4x1R DDR5-3600 4x2R DDR5-3600 Graphics Model: AMD Radeon™ Graphics Graphics Core Count: 2 Graphics Frequency: 2200 MHz USB Type-C® DisplayPort™ Alternate Mode: Yes Product ID Boxed: 100-100001405WOF

<p><strong>Name </strong>AMD Ryzen™ 5 9600X <strong>Family </strong>Ryzen <strong>Series </strong>Ryzen 9000 Series<strong> Form Factor</strong> Desktops , Boxed Processor <strong>Market Segment</strong> Enthusiast Desktop <strong>Regional Availability</strong> Global <strong>Former Codename</strong> Granite Ridge AM5 <strong>Processor Architecture</strong> Zen 5 <strong># of CPU Cores</strong> 6 <strong>Multithreading (SMT)</strong> Yes <strong># of Threads</strong> 12 Max. <strong>Boost Clock</strong> Up to 5.4 GHz <strong>Base Clock</strong> 3.9 GHz <strong>L1 Cache</strong> 480 KB <strong>L2 Cache</strong> 6 MB <strong>L3 Cache</strong> 32 MB <strong>Default TDP</strong> 65W <strong>Processor Technology for CPU Cores</strong> TSMC 4nm FinFET <strong>Processor Technology for I/O Die</strong> TSMC 6nm FinFET Package Die Count 2 Unlocked for Overclocking Yes AMD EXPO™ Memory Overclocking Technology Yes Precision Boost Overdrive Yes Curve Optimizer Voltage Offsets Yes AMD Ryzen™ Master Support Yes <strong>CPU Socket</strong> AM5 <strong>Supporting Chipsets</strong> A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850 CPU Boost Technology Precision Boost 2 Instruction Set x86-64 <strong>Supported Extensions</strong> AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 <strong>Thermal Solution </strong>(PIB) Not Included Recommended Cooler Premium air cooler recommended for optimal performance <strong>Max. Operating Temperature (Tjmax)</strong> 95°C<strong> Launch Date</strong> 08/08/2024 <strong>*OS Support </strong>Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit</p>
