LindyView other Lindy products →
Lindy 10m USB 3.0 Act Ext Slim
MPN: 43403
$135.00$140.91
Inc GST
Low stock
1 available
Description
LINDY 10m USB 3.0 Active Extension Slim
Specification
<h3>Features</h3>
<ul>
<li>10 metre USB 3.0 Active Extension Repeater Cable</li>
<li>Supports transfer rates up to 5Gbps</li>
<li>For even greater distances simply connect up to 5 cables in series</li>
<li>USB Power Adapter cable included</li>
<li>2 year warranty</li>
</ul>
<h3>Specifications</h3>
<h4>Connectors</h4>
<ul>
<li>Connector A: USB Type A Male</li>
<li>Connector B: USB Type A Female</li>
<li>Power: 2.5/0.7mm DC</li>
<li>Connector Housing Material: PVC</li>
<li>Connector Plating: Nickel plated</li>
<li>Pin Construction: Copper</li>
<li>Pin Plating: Gold</li>
<li>Dimensions (approx.) WxDxH:</li>
<ul>
<li>USB A Male: 41.1x16.5x9.5mm (1.61x0.64x0.37in)</li>
<li>USB A Female: 67.5x22x13.5mm (2.65x0.86x0.53in)</li>
</ul>
</ul>
<h4>Cable Construction</h4>
<ul>
<li>Standard: USB 3.2 / 3.1 Gen 1 / 3.0</li>
<li>Colour: Black</li>
<li>Type: Round</li>
<li>Jacket Diameter: 6.5mm (0.26in)</li>
<li>Jacket Material: PVC</li>
<li>Conductor Material: Tinned Copper</li>
<li>Conductor Gauge: 24AWG+24AWG+20AWG</li>
<li>Shielding: 75% Tinned Copper</li>
</ul>
<h4>Specifications</h4>
<ul>
<li>Supported Bandwidth: 5 Gbps</li>
<li>Nominal Attenuation: <23.0Db@2.5GHz (USB 3.0), <5.8Db@200MHz (USB 2.0)</li>
<li>Minimum Bend Radius: 80mm (3.14in)</li>
<li>Operating Temperature: 0°C - 40°C (32°F - 104°F)</li>
<li>Storage Temperature: -10°C - 60°C (14°F - 140°F)</li>
<li>Transmission Medium: Twisted Pair</li>
<li>Transmission Technology: USB 3.2 / 3.1 Gen 1 / 3.0</li>
</ul>
<h4>Miscellaneous</h4>
<ul>
<li>Packaging Type: Polybag</li>
<li>Packaging Dimensions: 324x335mm (12.76x13.19in)</li>
<li>Net Weight: 0.82kg (1.8lb)</li>
<li>Gross Weight: 0.86kg (1.9lb)</li>
<li>Warranty (Years): 2</li>
<li>Product Compliance: CE, FCC, RoHS & REACH, CP65</li>
</ul>
