Mean Well | HDR-60-24 | 24V Step Front DIN Rail Power Supply 2.5A 60W

<p>The MEAN WELL HDR-60-24 is a 60W, 24V, 2.5A ultra-slim DIN rail power supply, ideal for space-saving installations in industrial control and home automation systems. Its narrow 52.5mm (3SU) width allows for efficient use of enclosure space. This reliable power supply features a universal AC input range of 85~264VAC and boasts a low no-load power consumption of less than 0.3W, contributing to energy efficiency. Designed with a plastic housing for enhanced safety against electric shock, it operates within a wide temperature range of -30°C to +70°C through free air convection. The HDR-60-24 is equipped with protections against short circuit, overload, and over voltage, ensuring the safety and longevity of your connected devices. It is a suitable replacement for MDR series power supplies.</p> <h3>Features</h3> <ul> <li>Ultra-slim design with a width of 52.5mm (3SU)</li> <li>Universal AC input range: 85~264VAC (277VAC operational)</li> <li>Low no-load power consumption: &lt;0.3W</li> <li>Plastic housing for enhanced safety</li> <li>Cooling by free air convection</li> <li>LED indicator for power on</li> </ul> <h3>Specifications</h3> <ul> <li><strong>DC Output Voltage:</strong> 24V</li> <li><strong>Rated Output Current:</strong> 2.5A</li> <li><strong>Rated Output Power:</strong> 60W</li> <li><strong>Adjustable DC Output Voltage Range:</strong> 21.6~29V</li> <li><strong>AC Input Voltage Range:</strong> 85~264VAC (277VAC operational)</li> <li><strong>AC Input Current:</strong> 0.8A at 230VAC</li> <li><strong>Inrush Current:</strong> 60A at 230VAC</li> <li><strong>Efficiency:</strong> 90%</li> <li><strong>No Load Power Consumption:</strong> &lt;0.3W</li> <li><strong>Over Voltage Protection:</strong> 30~36VDC, re-power to recover</li> <li><strong>Overload Protection:</strong> 105~160% rated output, recovers once fault removed</li> <li><strong>Working Temperature:</strong> -30°C to +70°C (refer to datasheet for derating)</li> <li><strong>Mounting:</strong> DIN rail TS-35/7.5 or TS-35/15</li> <li><strong>Dimensions:</strong> 52.5mm x 90mm x 54.5mm (W x H x D)</li> <li><strong>Weight:</strong> 0.19kg</li> </ul> <h3>Warranty</h3> <p>3-Year Limited Warranty</p>
