CAT6A U/FTP Cable on Wooden Drum w/ LSZH Jacket | 305m Roll Blue

<p>This high-performance Category 6A networking cable provides a robust solution for 10G Ethernet applications. It is engineered with a U/FTP (Unshielded/Foiled Twisted Pair) construction, where each of the four conductor pairs is individually wrapped in an Al/Mylar foil screen. This superior shielding design is highly effective at minimising internal crosstalk (NEXT) and protecting against external electromagnetic interference (EMI), ensuring outstanding signal integrity for reliable high-speed data transmission up to 500MHz.<br><br>Featuring 23AWG solid bare copper conductors, this cable ensures excellent conductivity and minimal signal loss over distance. The conductors are insulated with a skin-foam-skin PE, and the cable includes a drain wire for simple and effective grounding of the individual pair shields. This design guarantees stable performance compliant with ANSI/TIA-568-C.2 and ISO/IEC11801 standards.<br><br>The cable is jacketed in a blue LSZH (Low Smoke Zero Halogen) compound. This safety-critical material is ideal for installation in public spaces, data centres, or areas with poor ventilation, as it emits minimal smoke and no toxic halogens when exposed to fire. <br><br>Supplied on a 305m drum, this cable is ready for large-scale network deployments. It has a nominal outer diameter of 7.0mm and includes a rip-cord, which allows for quick and easy removal of the outer jacket during installation, saving time and effort.</p><h3>FEATURES</h3><ul> <li>Category 6A performance supports 10G Ethernet</li> <li>U/FTP construction with individual Al/Mylar foil shield per pair</li> <li>23AWG solid bare copper conductors</li> <li>Blue LSZH (Low Smoke Zero Halogen) safety jacket</li> <li>Supplied on a 305m drum</li> <li>Complies with ISO/IEC11801 & ANSI/TIA-568-C.2</li> <li>Includes drain wire and rip-cord</li></ul><h3>SPECIFICATIONS</h3><ul> <li><strong>Category:</strong> Cat 6A U/FTP</li> <li><strong>Pairs:</strong> 4</li> <li><strong>Conductor:</strong> Solid Bare Copper</li> <li><strong>AWG:</strong> 23AWG</li> <li><strong>Conductor Diameter:</strong> 0.560mm (Nominal)</li> <li><strong>Insulation:</strong> Skin-foam-skin PE</li> <li><strong>Insulation Diameter:</strong> 1.30±0.05mm</li> <li><strong>Screening:</strong> Al/Mylar (per pair)</li> <li><strong>Drain Wire:</strong> Yes</li> <li><strong>Sheath Material:</strong> LSZH (Low Smoke Zero Halogen)</li> <li><strong>External O.D.:</strong> 7.0±0.5mm</li> <li><strong>Sheath Colour:</strong> Blue</li> <li><strong>Packing Length:</strong> 305m</li> <li><strong>Reference Standard:</strong> ISO/IEC11801, ANSI/TIA-568-C.2</li> <li><strong>Impedance (1.0-250.0MHz):</strong> 100±15&Omega;</li> <li><strong>Impedance (250.0-500.0MHz):</strong> 100±22&Omega;</li> <li><strong>Delay Skew (1.0-500.0MHz):</strong> &le;45ns/100m</li> <li><strong>DC Resistance (max):</strong> 9.38&Omega;/100m</li> <li><strong>DC Conductor Resistance Unbalance (max):</strong> 5.0%</li></ul><h3>WARRANTY</h3><p>3-Year Limited Warranty</p>
