Lindy 4K KVM Over IP Ext (R)
MPN: 38265
$431.00$450.00
Inc GST
Available to order
0 available
Description
Lindy 4K KVM Over IP Extender - Receiver
Specification
<h3>Features</h3>
<ul>
<li>Extends HDMI 4K30, USB HID and IR over an IP network</li>
<li>Supports point to point and point to multipoint installation up to 150m</li>
<li>HDMI 1.4 & HDCP 1.4 compliant</li>
<li>Requires a Gigabit Ethernet (1000BaseT) compliant network for multipoint installation</li>
<li>2 year warranty</li>
</ul>
<h3>Specifications</h3>
<ul>
<li>AV Interface: HDMI</li>
<li>Console Interface: USB</li>
<li>Interfaces Standard: HDMI 1.4, USB (HID)</li>
<li>Supported Bandwidth: 10.2Gbps</li>
<li>Maximum Distance: 150m (492.12ft) (Point to Point)</li>
<li>Maximum Resolution: 4K@30Hz (3840x2160@30Hz)</li>
<li>HDCP Support: HDCP 1.4</li>
<li>Supported Audio: Audio supported over HDMI signal</li>
<li>Separate Audio Ports: -</li>
<li>Transmission Protocol: IP</li>
<li>Transmission Medium: Cat.5e / 6</li>
<li>Laser Class (only for Fibre): -</li>
<li>Wavelength (only for Fibre): -</li>
<li>Special Features: IR Signal (25 to 56kHz) forwarding</li>
</ul>
<h4>Connectors</h4>
<ul>
<li>Transmitter KVM Interfaces: -</li>
<li>Transmitter Extension Port: -</li>
<li>Receiver Console Interface: HDMI (Female), 2 x USB Type A (Female), IR 3.5mm (Female)</li>
<li>Receiver Extension Port: RJ45</li>
<li>Bi-directional Ports: -</li>
<li>Other Interfaces: IR 3.5mm (Female)</li>
<li>Power: 5.5/2.1mm DC socket</li>
</ul>
<h4>Physical Properties</h4>
<ul>
<li>Dimensions (approx.) WxDxH: 165x80x21mm (6.5x3.15x0.83in)</li>
<li>Housing Material: Plastic</li>
<li>Net Weight: 0.2kg (0.45lb)</li>
<li>Operating Temperature: 0°C - 55°C (32°F - 131°F)</li>
<li>Storage Temperature: -10°C - 75°C (14°F - 167°F)</li>
<li>Humidity: 10 - 80% RH (non-condensing)</li>
<li>Power Requirements: 5VDC 2A</li>
<li>Colour: Black</li>
</ul>
<h4>Miscellaneous</h4>
<ul>
<li>Packaging Type: Carton box</li>
<li>Packaging Dimensions: 220x170x60mm (8.66x6.69x2.36in)</li>
<li>Gross Weight: 0.8kg (1.76lb)</li>
<li>Warranty (Years): 2</li>
<li>Certification: CE, FCC, RoHS, REACH</li>
</ul>
