Teltonika 5G COMBO MOBILE SMA ANTENNA

Technical Data Mounting type M6 Screw or Adhesive Enclosure material PC/PC+ABS RoHS compliant ✓ Cable length 3000 mm Weight 400 g Operating temperature -40 °C ~ +80 °C Operating humidity ≤ 90 % Ingress Protection Rating IP67 UV resistant ✓ 5G MOBILE MIMO ANTENNA Frequency range 600 ~ 960, 1427 ~ 2700, 3300 ~ 4200, 4400 ~ 5000 MHz Polarisation Linear Radiation pattern type Omni-directional Gain ≤ 4 dBi V.S.W.R ≤ 2.5 Impedance 50 Ω Connector type and count 4 x SMA Male Cable type 4 x LMR100

5G MIMO antenna with 4x SMA Male connectors Frequency: 600–960, 1427–2700, 3300–4200, 4400–5000 MHz Gain: ≤4 dBi VSWR: ≤2.5 Impedance: 50 Ω Cable: 4x LMR100 (3000 mm) Polarisation: Linear Radiation pattern: Omni-directional Mounting: M6 Screw or Adhesive Enclosure: PC/PC+ABS IP Rating: IP67 Temperature: –40 °C to +80 °C Humidity: ≤90% Weight: 400 g UV resistant, RoHS compliant
