MSI PRO B850-S EVO WIFI, AMD B850, AM5, Ryzen 9000/8000/7000, 4xDDR5 256GB 8200+MT/s OC, PCIe 5.0 x16, 3xM.2, 5G LAN, Wi-Fi 7, 3yr wty

MSI PRO B850-S EVO WIFI, AMD B850, AM5, Ryzen 9000/8000/7000, 4xDDR5 256GB 8200+MT/s OC, PCIe 5.0 x16, 3xM.2, 5G LAN, Wi-Fi 7, 3yr wty SPECIFICATIONS Model Name PRO B850-S EVO WIFI CPU Support Supports AMD Ryzen™ 9000 / 8000 / 7000 series Desktop Processors CPU Socket AMD Socket AM5 Chipset AMD B850 Chipset Expansion Slots 1 x PCIe 5.0 x16 slot 1 x PCIe 4.0 x4 slot Display Interface Support 4K@60Hz as specified in HDMITM 2.1, DisplayPort 1.4 – Requires Processor Graphics Memory Support 4 DIMMs, Dual Channel DDR5 – 8200+ MT/s Storage 1 x M.2 Gen5 x4 128Gbps slot 1 x M.2 Gen4 x4 64Gbps slot 1 x M.2 Gen4 x2 32Gbps slot 4 x SATA 6Gbps ports USB ports 4 x USB 10Gbps (2 Type-A + 2 Type-C) 4 x USB 5Gbps (4 Type-A) 8 x USB 2.0 LAN Realtek® 8126 5G LAN Wireless /Bluetooth Wi-Fi 7 Solution, Bluetooth 5.4 Audio 8-Channel (7.1) HD Audio with Audio Boost FEATURES •64MB BIOS A larger BIOS ROM capacity allows the motherboard to support next-level CPU upgrades with better compatibility. •Wi-Fi 7 Wi-Fi 7 is the latest wireless solution that takes a huge leap forward with multiple improvements to meet the traffic demand brought and the growing number of wireless devices. •5G Network Solution Featuring premium 5G LAN to deliver better network experience. •EZ Antenna EZ Antenna makes the process effortless by simply attaching fasteners to the motherboard without rotation. •EZ PCIe Clip II Allows for easy removal of the graphics card by pressing the taillike lock with one finger, even in the cramped case spaces. •Latest DDR5 Memory A huge step of DDR performance enhancement with the latest DDR5 memory and MSI Memory Boost technology. •Lightning Gen 5 The latest PCIe 5.0 solution with up to 128GB/s bandwidth for maximum transfer speed. •USB 10Gbps Type-C Lightning-fast data transfer and effortless connectivity for modern peripherals. •Frozr AI Cooling Detect CPU & GPU temperatures and automatically adjust system fan duty to a proper value.

CPU Support: AMD Ryzen 9000/8000/7000 series CPU Socket: AMD AM5 Chipset: AMD B850 Form Factor: ATX Memory: 4 DIMMs DDR5, up to 256GB, 8200+ MT/s OC Storage: 1x M.2 Gen5 x4 (128Gbps), 1x M.2 Gen4 x4 (64Gbps), 1x M.2 Gen4 x2 (32Gbps), 4x SATA 6Gbps Expansion: 1x PCIe 5.0 x16, 1x PCIe 4.0 x4 USB: 4x USB 10Gbps (2 Type-A + 2 Type-C), 4x USB 5Gbps (4 Type-A), 8x USB 2.0 LAN: Realtek 8126 5G LAN Wireless: Wi-Fi 7 Solution, Bluetooth 5.4 Audio: 8-Channel (7.1) HD Audio with Audio Boost Display: HDMI 2.1 (4K@60Hz), DisplayPort 1.4 Power: 12+2+1 VRM phases, 8+4 power connectors BIOS: 64MB VRM Design: 12+2+1 digital power phases
