MSI B840M GAMING WIFI6E, AMD B840, AM5, 2xDDR5 128GB, PCIe 4.0 x16, 2xM.2 PCIe4, 2.5G LAN, Wi-Fi 6E, USB 5G, HDMI/DP, 2yr wty

MSI B840M GAMING WIFI6E, AMD B840, AM5, 2xDDR5 128GB, PCIe 4.0 x16, 2xM.2 PCIe4, 2.5G LAN, Wi-Fi 6E, USB 5G, HDMI/DP, 2yr wty SPECIFICATION Chipset AMD B840 CPU Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors Socket AM5 Memory 2x DDR5 UDIMM, Maximum Memory Capacity 128GB Memory Support DDR5 8000 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s Ryzen™ 9000 Series Processors max. overclocking frequency: • 1DPC 1R Max speed up to 8000+ MT/s • 1DPC 2R Max speed up to 7200+ MT/s Supports AMD POR Speed and JEDEC Speed Supports Memory Overclocking and AMD EXPOTM Supports Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM, Clock Driver bypass mode only* * CUDIMM support and POR boot frequency may vary by CPU series, with manual overclocking available after boot. Certain CPUs may fail to boot, but future BIOS updates will improve compatibility. • Memory compatibility and supported speeds can vary depending on the CPU and memory configuration. For detailed information, please refer to the Memory Compatibility List available on the product’s Support page or visit https://www.msi.com/support/. Onboard Graphics 1x HDMI™ Support HDMI™ 2.1, maximum resolution of 4K 60Hz* 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz* *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. Slot 2x PCI-E x16 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x4 (From Chipset) PCI_E1 slot • Supports PCIe 4.0 x16 (For Ryzen™ 9000/ 7000 Series processors) • Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors) • Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processor) Audio Realtek® ALC897 Codec 7.1-Channel High Definition Audio Storage 2x M.2 M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G *Please refer to the manual for M.2 SSD heatsink restrictions. RAID Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices USB 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 4x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 1x USB 5Gbps Type C (Front) LAN Realtek® 8125D 2.5G LAN LED FEATURE 4x EZ Debug LED 1x EZ Memory Detection LED OPERATING SYSTEM Support for Windows® 11 64-bit

Chipset: AMD B840 Socket: AM5 Form Factor: Micro-ATX (mATX) Memory: 2x DDR5 UDIMM slots, max 128GB, support for DDR5 8000-5600 MT/s (OC) / 5600-4800 MT/s (JEDEC) CPU Support: AMD Ryzen 9000/8000/7000 series PCIe Slots: 2x PCI-E x16 (PCI_E1 Gen4 x16 from CPU, PCI_E2 Gen3 x4 from chipset) Storage: 2x M.2 PCIe 4.0 x4 (supports 2280/2260), 4x SATA 6G Video Output: 1x HDMI 2.1 (4K 60Hz), 1x DisplayPort 1.4 (4K 60Hz) Audio: Realtek ALC897 codec, 7.1-channel high-definition audio LAN: Realtek 8125D 2.5G LAN Wireless: Wi-Fi 6E, Bluetooth 5.3 USB: 4x USB 5Gbps Type-A (rear), 2x USB 5Gbps Type-A (front), 1x USB 5Gbps Type-C (front), 2x USB 2.0 (rear), 4x USB 2.0 (front) Power Connector: 8-pin CPU power Debug Features: 4x EZ Debug LED, 1x EZ Memory Detection LED OS Support: Windows 11 64-bit Warranty: 2 years
