SHARP SDM HD-Base-T Interface Card. 1x RJ45 as HDbT Link IN. Up to 4K@60Hz (depending on HDbT Transmitter used). Compatible with: MExx1, Mxx1 (43''-98''), Mxx1-2, PN-Mxx2 (43''-98''), MAxx1, Pxx5 & PN-Pxx6 Displays ONLY
One single cable only - HDBaseT delivers video, audio, Ethernet and controls over a single cable, enabling to reduce the cable assortment down to one single cable.
Easy set-up and operation - Time saving installation using well known cable types and working Plug & Play saving installation cost.
Wide range of applications - Ideally suited for Rental & Staging, Leisure & Museums, Corporate & Education and all other applications that need to cover long cable distances.
Seamless and fully embedded - The Intel® SDM form factor provides a compact and fully embedded solution ensuring that all connectors are integrated including Power, Video & Audio Signals and RS232.
100% compatibility and enhanced feature-set - in combination with supported NEC large format displays
Specifications
SDM-HDBT: 100015712
Interfaces Frontside: 1x RJ45 as HDBaseT Link In; 1x IR in; 1x IR out
Max. resolution: UHD@60Hz (8bit) with CAT6a/CAT7 cables, up to 100m; FHD@60Hz (12bit) with CAT6a/CAT7 cables, up to 100m; FHD@60Hz (8bit), up to 150m (Long Reach Mode, depending on HDBT transmitter)
Power Consumption max. [W]: 9W
Operating Temperature [°C]: 0-40
Net Weight (kg): 0.3
Gross Weight (kg): 0.330
Size / Gross Dimensions (m): tbd
Compatibility: All NEC Large Format Displays accepting Intel® Smart Display Module Large
Warranty: 3 Years warranty, additional services available
