SHARP 12G SDI Interface Board

Features

• Upgrade to latest professional video transmission - 12G SDI is the latest technical standard of the Serial Digital Interface (SDI) and backwards compatible with HD-SDI, 3G and 6G versions.
• Latency free - transmit video signals, e.g. video cameras with no delay from the camera to the display; in combination with NEC MA Series „low latency“ mode the perfect combination.
• Seamless and fully embedded - The Intel® SDM form factor provides a compact and fully embedded solution ensuring that all connectors are integrated including Power, Video & Audio Signals.
• 100% compatibility and enhanced feature-set - in combination with supported NEC large format displays.
• High reliability - Ideally suited for 24/7 operation due to the use of industrial grade components

Specifications

• SDM-12G SDI Interface Board: 100015711
• Interfaces Frontside: 1x BNC for SDI IN; 1x BNC for SDI loop-out
• Interfaces backside: Internal Intel® SDM PCIe x8 interface
• Supported Resolution: 12G: up to 2160p@60Hz; 3G: up to 1080p@60Hz; 1.5G: up to 1080p@30Hz
• Maximum Cable Length: 12G: 70m; 3G: 190m; 1.5G: 260m
• Power Consumption max. [W]: 9.5W
• Operating Temperature [°C]: 0-40
• Net Weight (kg): 0.230
• Gross Weight (kg): 0.270
• Size / Gross Dimensions (m): 0.29 x 0.21 x 0.07
• Compatibility: All NEC Large Format Displays accepting Intel® Smart Display Module Small & Large
• Warranty: 3 Years warranty, additional services available
• External Adapter: 100015613 SDM Standalone Adapter
