CyberPower RT33010KE RT33 3-3Phase Rack/Tower 10kVA/10kW UPS - 2 Year RTB WTY

CyberPower RT33010KE RT33 3-3Phase Rack/Tower 10kVA/10kW UPS - 2 Year RTB WTY UPS Systems (3-Phase) VA: 10000 Watts: 10000 Rated Input Current ( A ) 20 Rated Output Voltage ( Vac ) Line to Neutral (L-N):220, 230, 240 Vac, Line to Line (L-L):380, 400, 415 Vac Outlets Hardwire Terminal Block x 1

<h3>Features</h3> <ul> <li>Three-phase Design</li> <li>ECO Mode</li> <li>Flexible System Configuration</li> <li>Rack Modular Design</li> <li>Color LCD Panel</li> <li>Dual Inputs</li> <li>Generator Compatible</li> <li>Battery Cold Start</li> <li>SNMP/HTTP Remote Management Capability (Optional)</li> <li>Extended Battery Module (EBM)</li> <li>Online (Double Conversion) UPS Topology</li> <li>High Density Design</li> <li>High Output Power Factor</li> <li>Rack/Tower Convertible Configurations</li> <li>LCD Touch Panel</li> <li>UPS Parallel Expansion</li> <li>Pure Sine Wave Output</li> <li>Smart Battery Management (SBM)</li> <li>PowerPanel Management Software</li> </ul> <h3>Specifications</h3> <h4>General</h4> <ul> <li>Phase: Three Phase</li> <li>Form Factor: Rackmount, Tower</li> <li>UPS Topology: Online Double Conversion</li> <li>Energy Saving Technology: ECO Mode Efficiency ? 98%</li> <li>Normal Mode Efficiency ( % ): 95%</li> <li>Battery Mode Efficiency ( % ): 94.5%</li> <li>Active PFC Compatibility: Yes</li> <li>Parallel Expansion (Max. Units): 4</li> </ul> <h4>Input</h4> <ul> <li>Dual Power Inputs: Yes</li> <li>Generator Compatibility: Yes</li> <li>Nominal Input Voltage ( Vac ): Line to Neutral (L-N):220, 230, 240 Vac, Line to Line (L-L):380, 400, 415 Vac</li> <li>Input Voltage Range ( Vac ): Line to Neutral (L-N): 132 ~ 276 Vac; Line to Line (L-L): 228 ~ 478 Vac</li> <li>Configurable Voltage Range ( Vac ): Line to Neutral (L-N): 220 ~ 250 Vac; Line to Line (L-L): 380 ~ 435 Vac</li> <li>Input Frequency ( Hz ): 50 &plusmn; 3 / 60 &plusmn; 3</li> <li>Input Frequency Range ( Hz ): 40 ~ 70</li> <li>Rated Input Current ( A ): 20</li> <li>Current Harmonic ( % ): 4%</li> <li>Input Power Factor: 0.99</li> <li>Input Connector Type: Hardwire Terminal Block</li> </ul> <h4>Output</h4> <ul> <li>Capacity (VA): 10000</li> <li>Capacity (Watts): 10000</li> <li>On Battery Waveform: Pure Sine Wave</li> <li>Output Voltage Setting: Configurable</li> <li>Output Frequency Setting: Configurable</li> <li>Rated Output Voltage ( Vac ): Line to Neutral (L-N):220, 230, 240 Vac, Line to Line (L-L):380, 400, 415 Vac</li> <li>Output Voltage Tolerance ( % ): 1.5 %</li> <li>Output Frequency ( Hz &plusmn; % ): 50 &plusmn; 0.1 / 60 &plusmn; 0.1</li> <li>Power Factor: 1</li> <li>ECO Mode Voltage Tolerance: &plusmn; 10 %</li> <li>Overload Protection: Internal Current Limiting, Circuit Breaker, Fuse</li> <li>Overload Protection (Line Mode): 105~110% Load for 60 min, 110~125% Load for 10 min, 125~150% Load for 1 min, ?150% Load Immediately</li> <li>Overload Protection (Battery Mode): 105~110% Load for 60 min, 110~125% Load for 10 min, 125~150% Load for 1 min, ?150% Load Immediately</li> <li>Overload Protection (Bypass Mode): 125~130% Load for 10 min, 130~150% Load for 1 min, 150~400% Load for 1 sec, ?400% Load Immediately</li> <li>Crest Factor: 3 : 1</li> <li>Harmonic Distortion (Linear Load): THD?1%</li> <li>Harmonic Distortion (Non-linear Load): THD?5%</li> <li>Internal Bypass: Automatic Bypass, Manual Bypass</li> <li>Outlet Type: Hardwire Terminal Block x 1</li> <li>Typical Transfer Time ( ms ): 0</li> </ul> <h4>Battery</h4> <ul> <li>Compatible Battery Types: VRLA, AGM, Gel, Wet</li> <li>Recharge Power ( % ): Default 10% (Selectable from 1~20% x UPS Capacity)</li> <li>Recharge Power Setting: Configurable</li> <li>Charger Voltage Tolerance ( % ): &le; 1 %</li> <li>Start On Battery: Yes</li> <li>Smart Battery Management (SBM): Yes</li> <li>User-replaceable: No</li> <li>Battery Solution: Extended Battery</li> <li>Battery Voltage ( V ): &plusmn;240 (480)</li> <li>Compatible Extended Battery Module (EBM): BM240V63ART3U</li> <li>Compatible Extended Battery Cabinet (EBC): SMBF17, SMBF20, SMBF26, SMBF33, SMBF40, SMBF65, BCA100N125, BCA12N63, BCA20N125, BCA40N125</li> <li>External Battery Quantity: 12V x 40pcs</li> </ul> <h4>Surge Protection &amp; Filtering</h4> <ul> <li>EMI/RFI Filtration: Yes</li> </ul> <h4>Management &amp; Communications</h4> <ul> <li>LCD Panel: Yes</li> <li>LCD Types: Color LCD, LCD Touch Panel</li> <li>LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault &amp; Warning, Other Information, Event &amp; Log</li> <li>LCD Setting &amp; Control: Mode Setting, Input &amp; Output, Battery Setting, Communication, Event &amp; Log, Security Setting, Language</li> <li>LED Indicators: Yes</li> <li>Serial Port: RS232 x 1 + RS485 x 1 + Dry Contact x 1</li> <li>Dry Contact (with Relay): Yes</li> <li>Audible Alarms: Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault, Replace Battery</li> <li>Management Cable ( pcs ): Power Cord x1</li> <li>Power Management Software: PowerPanel Business (Recommended)</li> <li>SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205</li> </ul> <h4>Physical</h4> <ul> <li>Compatible with Racks (3 Phase): Yes</li> <li>Enclosure Construction: Metal</li> <li>Color: Black</li> <li>Ingress Protection: IP20</li> <li>Rackmount Rail: Yes</li> <li>Rackmount Ears: Yes</li> <li>High Density Design: Yes</li> <li>Dimensions (WxHxD) (mm.): 438 x 130 x 750</li> <li>Weight (kg.): 25</li> <li>Installed Rack Height ( U ): 3</li> </ul> <h4>Shipping Dimensions</h4> <ul> <li>Dimensions (WxHxD) (mm.): 575 x 270 x 950</li> <li>Weight (kg.): 32.4</li> </ul> <h4>Environmental</h4> <ul> <li>Operating Temperature (&deg;C): 0 ~ 40</li> <li>Operating Relative Humidity (Non-condensing) ( % ): 0 ~ 95</li> <li>Operating Elevation ( feet/meters ): &le;1000, Load Derated 1% per 100m from 1000m and 2000m</li> <li>Storage Temperature (&deg;C): -40 ~ 70</li> <li>Storage Relative Humidity (Non-condensing) ( % ): 0 ~ 95</li> <li>Audible Noise at 1.0M from Surface of Unit ( dBA ): 58</li> </ul> <h4>Certifications</h4> <ul> <li>Certifications: CE, IEC62040-1, EN 62040-2, EN 61000-3-11, EN 61000-3-12</li> <li>RoHS: Yes</li> </ul> <h4>Special Features</h4> <ul> <li>Phase Configuration (3 Phase): Yes</li> </ul> <h4>Warranty</h4> <ul> <li>Product Warranty Period (Year): 2</li> <li>Battery Warranty Period (Year): 2</li> </ul>
